Whakaahuatanga Hua
3V100 raupapa pneumatic solenoid valves e whakamahia whanuitia ana mo te whakahaere tika i te rere o te hau i roto i nga punaha aunoatanga pneumatic. He tinana kiato me te hoahoa ara 3/2, he pai enei vaolo mo nga tono tiaki mokowā-e hiahia ana te whakawhiti pono me te whakautu tere. Hei kaiwhakarato pneumatic ngaio i Haina, ka tukuna e matou he riipene raupapa AIRTAC 3V100 taketake me nga utu whakataetae o te rohe me nga hongere rapu pumau hei tautoko i o kaupapa miihini puta noa i te ao.
|
Me pehea te Ota3V100 Raupapa Pneumatic Solenoid Valve |
||||||||
|
3V 1 10 06 KORE A □ □ |
||||||||
|
① ② ③ ④ ⑤ ⑥ ⑦ ⑧ |
||||||||
|
①Tauira |
②Waehere |
③Momo |
④Rahi tauranga |
⑤Momo mahi |
⑥Ngaohiko Paerewa |
⑦Te urunga hiko |
⑧Momo miro |
|
|
3V:Solenoid |
1:100 Raupapa |
10:Solenoid kotahi |
M5:M5 |
NC: Ko te tikanga |
A:AC220V |
Patea:Tera |
M5 |
1/8" |
|
一 |
Patea:PT |
|||||||
|
20:Solenoid takirua |
Kaore tenei waehere |
|||||||
Tena koa whakapā mai ki a matou i tenei ra mo te katoa o nga korero mo nga hua, tuhinga hangarau, me nga korero whakataetae i runga i nga reera solenoid raupapa 3V100 hei whakarei ake i o punaha aunoa.
3V100RangatūPneumatic Solenoid ValveTawhā Hangarau
|
3V100RangatūPneumatic Solenoid Valve Whakatakotoranga Matua |
||||
|
Tauira |
3V110-M5 |
3V120-M5 |
3V110-06 |
3V120-06 |
|
Wai |
Te hau(kia tātarihia e te huānga tātari 40μm) |
|||
|
Whakaari |
Kaiurungi-roto, kaiurungi-waho ranei |
|||
|
Rahi tauranga [Note1] |
M5 |
1/8" |
||
|
Rahi orifice(Cv)[Note3] |
3V110-06,3V120-06:10.2mm²(Cv=0.6) |
|||
|
Momo takirere |
3 tauranga2 turanga |
|||
|
Whakahinuhinu [Note2] |
Kaore e hiahiatia |
|||
|
Te pehanga whakahaere |
0.15~0.8MPa(21~114psi) |
|||
|
Te pehanga tohu |
1.2MPa(175psi) |
|||
|
Te pāmahana |
-20~70 tohu |
|||
|
Rauemi o te tinana |
konumohe konumohe |
|||
